Smart security catering for every household

Step into a realm of enhanced indoor security with the latest H6c Pro. Thanks to its rotation and patrol feature, this smart camera dynamically captures every corner with no detail unnoticed. Responding with unmatched agility to human motion and sudden clamors, it propels tracking into new levels. With a newly designed touch call button, the H6c Pro ensures you’re always connected to your family, no matter the distance.

Elevating visual protection in every angle

The H6c Pro unveils a panoramic vision over your indoor domain. It can deftly rotate to capture every detail in your room, such as the position of your little kids or your flurry pets, protecting your home from day to night.

The H6c Pro pans and tilts automatically to eliminate blind spots with its unique patrol mode . You can even customize patrol pattern in accordance with your very special home, leaving no corner uncovered.

Get the notifications that matter

A lot of activities go on inside your home. Don’t want to get alerted repeatedly when your curtains flutter in the wind? The H6c Pro is smart enough to identify human activities in particular. You can choose to get alerted only when somebody is detected on camera.

Powered by advanced human motion detection, the H6c Pro swiftly locks onto people’s behaviors, rotating to track their ongoing activities. Be it your parents’ steps or your toddlers’ playful moves, this camera ensures no lively scene goes unnoticed.

Connect to your loved ones

Stay connected with your families is of great significance. No worries if your baby cries, this smart camera keeps you informed when human voices are detected. What’s more, a simple tap on the camera is all it takes when your elderly parents need to reach out to you, which is the simplest way to start a video call.

Picture clearly in the dark

No more blurry night recordings. The H6c Pro offers enhanced clarity even in the night time. The dark environments are now revealed in crystal-clear night vision, granting you a new level of assurance.

H6c Pro

Elevating visual protection in every angle

Specifications

Specifications
Model	CS-H6c-R105-1L2WF
Camera
Image sensor	F1.6@1/3″ Progressive Scan CMOS
Shutter Speed	Self-adaptive shutter
Lens	4mm, view angle: 90°(Diagonal), 80° (Horizontal), 43°(Vertical)
Lens Mount	M12
Day & Night	IR-cut filter with auto-switching
DNR	3D DNR
WDR	Digital WDR
Compression
Video Compression	H.264/H.265
Video Bit Rate	Adaptive bit rate.
Max. Resolution	1920 × 1080
Frame Rate	Max:25fps; Self-Adaptive during network transmission
Network
Smart Alarm	Motion detection, Human Detection, Human Tracking, Big Noise Detection, Auto patrol
Wi-Fi Pairing	AP paring
Protocol	EZVIZ cloud proprietary protocol
Interface Protocol	EZVIZ cloud proprietary protocol
Interface
Storage	Micro SD card slot (Max. 512G)
Power	TYPE-C
Wired Network	RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard	IEEE802.11b, 802.11g, 802.11n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	Supports 20MHz
Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate	11b: 11Mbps, 11g :54Mbps, 11n :72Mbps
Output Power(EIRP)	19 dBm
Antenna Gain	1.9 dBi
General
Operating Conditions	-10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
Power Supply	DC 5V/1A
Power Consumption	5W max
IR Range	MAX. 10 meters(32.81ft)
Dimensions	88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
Packaging Dimensions	103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
Bare Weight	218g(0.48lb)
In the box
In the box	– Camera
	– Power Adapter
	– Power Cable
	– Drill Template
	– Mounting Plate
	– EZVIZ Screw Kit
	– Regulatory Information
	– Quick Start Guide
Certifications
Certifications	CE / UL / WEEE / REACH / RoHS / UKCA
